CAD software is widely used by manufacturers for unfolding sheet metal parts. Some of this software is 2D-based, with no assembly model support, and used solely for sheet metal parts. Real world parts include non-sheet metal components and require a solution that can visualize the entire assembly. AMADA offers SheetWorks as a solution that expands the range of what CAD software can achieve. The advanced SheetWorks modeling tools help finalize sheet metal parts and assemblies with precision. Its use of 3D visualization for design, development and modeling greatly enhances overall quality and efficiency

SheetWorks Features

• Draw Model - Assign a structural member to each segment in a wire frame sketch to create the tube model.
• Pattern Input - Similar shape tubes of different sizes can be created by entering parameters.
• Import - The tube models created in other 3D CAD programs can be imported for use.
• Set Connection Pattern - Position tabs and notches can be inserted to reduce assembly and welding time.
• Unfold - Add logos or graphics after unfolding the tube.
